[shortdesc] 2MP image quality, ARTPEC-9 chipset, OptimizedIR 45m+ range, Forensic WDR, AI analytics, IP66/IK10 outdoor dome [/shortdesc]
[properties]
| Model |
AXIS P3275-LVE |
| Product Type |
Outdoor 2 MP AI-powered Dome Camera |
| Image Sensor |
1/2.8" progressive scan RGB CMOS; 2.9 micrometer pixel size |
| Lens Options |
Varifocal 3.4–9.8 mm (10 mm version; Varifocal 10.8–28.2 mm (29 mm version |
| Field of View |
10 mm: 100°–32° H / 52°–18° V; 29 mm: 29.1°–11° H / 16.4°–6.2° V |
| Minimum Illumination |
Color: 0.08 lux; B/W: 0.02 lux; 0 lux with IR on |
| IR Illumination Range |
10 mm: 40 m or more; 29 mm: 45 m or more |
| WDR |
Forensic WDR up to 120 dB |
| Operating Temperature |
-40°C to 50°C (-40°F to 122°F |
| Storage Temperature |
-40°C to 65°C (-40°F to 149°F |
| Ingress Protection |
IP66, NEMA 4X |
| Impact Resistance |
IK10-rated |
| Power |
PoE IEEE 802.3af/at Type 1 Class 3; Max 10 W |
| Dimensions |
See datasheet diagram |
| Weight |
840 g (10 mm, 850 g (29 mm |
[/properties]
[specifications]
| Video Compression |
H.264 Baseline/Main/High; H.265 Main; AV1; Motion JPEG |
| Max Resolution |
1920 x 1080 (16:9; 1440 x 1080 (4:3; 1280 x 800 (16:10 |
| Frame Rate |
Up to 50/60 fps in all resolutions |
| Video Streams |
Up to 20 unique streams; VBR/ABR/MBR |
| Image Enhancements |
Lightfinder 2.0, OptimizedIR, 2D/3D noise reduction, Defog, Barrel distortion correction |
| Audio Features |
AGC, 10-band equalizer, configurable duplex audio, mic/line-in, audio output via speaker pairing/portcast |
| Audio Encoding |
LPCM 24bit, AAC-LC, G.711 PCM, G.726 ADPCM, Opus |
| Network Protocols |
IPv4/IPv6, HTTPS, SRTP, SIP, SNMP, MQTT, FTP/SFTP, QoS, NTP/NTS, ONVIF G/M/S/T |
| Analytics (Included |
AXIS Object Analytics, AXIS Image Health Analytics, AXIS Scene Metadata, AXIS Live Privacy Shield |
| Axis Object Analytics |
Detect/classify humans & vehicles; line crossing; area monitoring; counting; PPE monitoring |
| Onboard Storage |
microSD/microSDHC/microSDXC; SD card encryption (AES-XTS-Plain64 256bit |
| Cybersecurity |
Axis Edge Vault, Secure Boot, Signed OS, FIPS 140-3 Level 3 secure keystore |
| I/O |
1 configurable supervised input/digital output (12 V DC output, max load 25 mA |
| Operating Humidity |
10–100% RH (condensing |
| DORI (10 mm lens |
Detect 48–135 m; Observe 19–54 m; Recognize 9.6–27 m; Identify 4.8–14 m |
| DORI (29 mm lens |
Detect 149–394 m; Observe 59–157 m; Recognize 30–79 m; Identify 15–39 m |
[/specifications]
[accesories]
| Included in the Box |
Camera; Weathershield; Installation guide; Terminal block connector; Connector guard; Cable gasket; Owner authentication key |
| Optional - Portcast Accessories |
AXIS T61 MkII Audio and I/O Interface Series; AXIS D6210 Air Quality Sensor |
| Optional - Installation Tools |
AXIS T8415 Wireless Installation Tool |
| Optional - Mounting Accessories |
AXIS TP3206-E Recessed Mount; AXIS TP3103-E Pendant Kit |
| Optional - Storage Accessories |
AXIS Surveillance Cards |
[/accesories]
AI-Powered Outdoor Surveillance with Precision & Reliability
The AXIS P3275-LVE is a robust 2 MP outdoor dome camera built on the ARTPEC-9 platform, offering superior image quality, advanced AI analytics, and resilient operation in harsh environments. With OptimizedIR and Forensic WDR, and deep learning capabilities powered by a dedicated DLPU, it provides highly accurate detection and classification of humans and vehicles even in challenging lighting. Furthermore, it includes AXIS Live Privacy Shield for real-time monitoring while protecting privacy. Engineered for 24/7 professional surveillance, it combines performance, cybersecurity, and durability in a single compact form factor.
Key Benefits & Features
-
ARTPEC-9 Processing Power: Accelerated edge analytics enable precise classification, tracking, and counting of people and vehicles.
-
Superior 2 MP Image Quality: Forensic WDR up to 120 dB, Lightfinder 2.0, and low-light performance deliver clear, clean footage around the clock.
-
Long-Range OptimizedIR: Built-in 850 nm IR illumination supports detailed nighttime monitoring with a reach of 45 m (148 ft or more, ideal for long-distance surveillance.
-
Advanced Cybersecurity: Axis Edge Vault secures identities, encrypts storage, and enforces secure boot for tamper-resistant operations.
-
Live Privacy Protection: Features AXIS Live Privacy Shield for dynamic masking to safeguard personal data in real-time.
-
Rugged Outdoor Build: Rated IK10, IP66, and NEMA 4X for vandal resistance, impact protection, and all-weather reliability.
Ideal Use Cases
- Commercial building perimeters requiring AI-driven intrusion detection
- Industrial facilities with demanding environmental conditions
- Transport hubs such as parking areas, terminals, and loading zones
- Retail exteriors needing precise human and vehicle analytics
- Municipal, security, and smart-city surveillance projects
Technical Specifications
-
Resolution: 1920 x 1080 (2 MP, up to 50/60 fps in all resolutions
-
Lens Type (29 mm: Varifocal 10.8–28.2 mm, F1.70–1.76 with P-Iris control
-
Field of View (29 mm: Horizontal 29.1°–11°; Vertical 16.4°–6.2°
-
Minimum Illumination: 0.08 lux (color, 0.02 lux (B/W, 0 lux with IR
-
IR Range: 45 m (148 ft or more with OptimizedIR
-
WDR: Forensic WDR up to 120 dB
-
Onboard Analytics: AXIS Object Analytics, Image Health Analytics, Scene Metadata, Live Privacy Shield
-
SoC: ARTPEC-9 with DLPU for deep learning processing
-
Durability: IK10, IP66, NEMA 4X outdoor rating
-
Operating Temperature: -40°C to 50°C (-40°F to 122°F
-
Power: PoE IEEE 802.3af/at, max 10 W
